What is anti-static tile?
Anti-static ceramic tile is a new anti-static material and can overcome the problems of other materials: such as epoxy and melamine, PVC anti-static coating, flooring, anti-static rubber sheet and other polymer materials easy to aging, not wear-resistant, easy to pollution, durability and not good fire prevention. Overcoming the shortcomings of the above anti-static materials, anti-static ceramic tile is compatible with the advantages of ceramic wall and floor tiles which are beautiful and durable, fire-resistant, non-slip, pressure-resistant, wear-resistant, corrosion-resistant, anti-fouling, waterproof and anti-penetration, low discharge radiation, environmental health and easy to build. And anti-static tile is a permanent anti-static, with high-grade art decorative effect of a functional ceramic tile.
Sizes: 600x600MM, 800x800mm, 600x1200mm and etc.
What are the advantages of anti-static tiles?
The anti-static tile completely eliminates the problem of warping, breaking, and not easy to clean of ordinary HPL and PVC veneer flooring, and is a rapidly developing new generation product.
Anti-static tile research and development success completely solve the world’s problems, with its stable anti-static performance and excellent quality will certainly regulate the entire anti-static market to provide protection for human production and life.
At present, anti-static tile is widely used in anti-static raised floor surface, such as all-steel ceramic surface anti-static floor, composite ceramic surface anti-static floor and other wrench base.
First, not affected by the environment, through the body have permanent, stable anti-static properties, body resistance and surface resistance are less than 5 × 108Ω.
Second, excellent heat resistance, high temperature resistance up to 1200 ℃ but conductivity unchanged.
Third, wear resistance, corrosion resistance, acid and alkali resistance, oil resistance, flame retardancy, anti-penetration is incomparable to other materials.
Fourth, ceramic material, never aging.
Five, non-toxic, no smell, non-radiation, is a environment friendly product.
Sixth, the color variety can be arbitrarily selected.
Seven, the amount of dust is small and can meet the higher level of clean and quiet environment requirements with the use of seam sealer .
Eight,Convenient construction, suitable for all kinds of old and new buildings.
What is the application scope of anti-static ceramic tiles?
Anti-static ceramic tiles can be used in many places:
- Computer rooms, microwave communication station rooms, mobile communication rooms
- Program-controlled telephone production workshop floor, program-controlled telephone exchange room
- TV transmitter control room, radio control room
- Electric power control and dispatch center, subway dispatch center
- Transportation dispatching center
- Petrochemical production workshop
- Clean workshop for integrated circuit production
- Assembly workshop of electronic instrument factory
- Hospital operating room, anesthesia room, oxygen bar room
What are the differences between anti-static ceramic tiles and normal ceramic tiles?
The difference between anti-static ceramic tiles and normal ceramic tiles definitely lies in its anti-static function. With the increase of electrical and electronic equipment in people’s lives, there are dangers everywhere. Although some products themselves are with protection, but with a second layer of protection, then the living environment will be safer and more practical, which is the performance of normal ceramic tiles can not reach. Being anti-static because the factory use some special materials and in the physical testing of its internal content is simply controlled. And in a variety of production, professional staff will also carry out a second check, to make sure customers will get a very perfect product.
Another difference between normal ceramic tiles and anti-static ceramic tiles is also that the overall construction of anti-static tiles is very convenient. As anti-static ceramic tile has the function of anti-static itself, so in the process of construction, it will not be affected by other aspects but can be tiling better.It is worth clarifying that many materials no longer require special preparation prior to construction, which reduces the overall construction time and enhances the excellent results in all aspects. For anyone, the excellent nature of this efficiency produced is also due to its own composition superior to previous products and so anti-static ceramic tiles can be installed in different building.
Compared with normal ceramic tiles, though the advantage of anti-static tiles is obvious, but the price of anti-static tiles is also a little bit higher than normal ceramic tiles. Therefore, anti-static ceramic tiles are not widely used more yet.
How to install anti-static ceramic tiles?
Anti-static tiles are physically modified by adding anti-static functional powder during the tile firing process, so the anti-static performance is very stable. The resistance value is between 10 to the power of 6 to 9 ohms, and the construction is easy, ordinary plasterers can do the tiling.
Installation technique:
1,Anti-static tile floor project should include the construction of grass-roots level, combined layer, surface layer and anti-static grounding system.
2,The combined layer mortar should be used dry cement mortar with the volume ratio of 1:3, and the thickness should be 25~35㎜, and the surface should be brushed with a cement slurry.
3,The cement mortar bonding layer should be added resistance reduction agent in proportion. The weight ratio of cement mortar and conductive powder is 1:0.003.
4,Laying conductive copper tape on cement mortar bonding layer, the longitudinal spacing should be 3000㎜ and the transverse spacing should be 4800㎜. After the laying is finished, a multimeter should be used to test the conductive copper tape so that all of them form a pathway, and do the concealed project acceptance record.
5,Tiling should be kept in place horizontally, lightly hit with rubber hammer to make it bond closely with mortar, and adjust its surface flatness and seam width (1-3mm).
6,When tiling anti-static tiles In the cement mortar bonding layer, the floor bottom surface should be clean. Joints shall be set between slabs in accordance with the design requirements. The slab against the wall should be closely fit, shall not use mortar caulking.
7,The slab hooking should use the same variety, the same strength grade, the same color cement or other high-quality hooking materials, and do a good job of maintenance and protection. In the clean plant, the joints should be hooked with non-dusty hooking materials.
8, The ground tiled with tiles should be flat, straight lines and set correctly. Between the floor and the bonding layer should be pasted tightly, no empty drum.
9,The width of the splicing joints of the slab shall meet the design requirements. When the design is not specified, the width of the splice should not be larger than 3mm.
10,After the anti-static tile is laid, the surface should be covered with fabric and kept moist, and the maintenance time should not be less than 5 days. After the compressive strength of cement mortar of the combined layer reaches the requirement, it can be cleaned with water or 3%~15% oxalic acid or neutral detergent solution to make the surface clean.
11,After the surface of the floor is dry, the grounding connection should be made as required.
12,The outdoor grounding part of the electrostatic grounding system should be made independent grounding; for the areas which cannot reach the required conditions, it can be connected to the grounding bus. The number of grounding poles depending on the soil geological conditions, outdoor grounding resistance should not be greater than 30Ω.
13,When the electrostatic grounding and lightning grounding, DC work grounding, AC work grounding, safety protection grounding shared a ground, the system grounding resistance should be less than 1Ω, and in addition to the lightning grounding branch, electrostatic and other grounding branch should be installed to ensure the safety of lightning sensitive resistors.
After giving the short brief about anti-static ceramic tiles, have you got some idea about it? As known by more and more people, anti-static tiles will be used more and more. T&A CERAMICS manufacturer will offer you kinds of choices for ceramic tiles no matter you need normal ceramic tiles or anti-static ceramic tiles. Welcome to contact us if you have any enquiry or any advice.
